二维码离线传输2.0

import os
import base64
import hashlib
import json
import time
import uuid
from flask import Flask, request, render_template, send_file, jsonify, redirect, url_for
import qrcode
from cryptography.fernet import Fernet

app = Flask(__name__)

# --- 配置 ---
UPLOAD_FOLDER = 'uploads'
QR_CODE_FOLDER = 'qr_codes'
RECEIVED_FOLDER = 'received_files'
app.config['UPLOAD_FOLDER'] = UPLOAD_FOLDER
app.config['QR_CODE_FOLDER'] = QR_CODE_FOLDER
app.config['RECEIVED_FOLDER'] = RECEIVED_FOLDER

# 确保目录存在
os.makedirs(UPLOAD_FOLDER, exist_ok=True)
os.makedirs(QR_CODE_FOLDER, exist_ok=True)
os.makedirs(RECEIVED_FOLDER, exist_ok=True)

# 存储传输会话信息 {session_id: {'key': key, 'chunks': [...], 'metadata': {...}}}
transfer_sessions = {}

# --- 辅助函数 ---

def calculate_sha256(file_path):
"""计算文件的 SHA-256 哈希值"""
sha256_hash = hashlib.sha256()
with open(file_path, "rb") as f:
# Read and update hash string value in blocks of 4K
for byte_block in iter(lambda: f.read(4096), b""):
sha256_hash.update(byte_block)
return sha256_hash.hexdigest()

def split_data(data, chunk_size):
"""将字节数据分割成指定大小的块"""
chunks = []
for i in range(0, len(data), chunk_size):
chunks.append(data[i:i + chunk_size])
return chunks

def generate_qr_code(data_str, filename):
"""生成二维码并保存为文件"""
qr = qrcode.QRCode(
version=1,
error_correction=qrcode.constants.ERROR_CORRECT_L,
box_size=10,
border=4,
)
qr.add_data(data_str)
qr.make(fit=True)

img = qr.make_image(fill_color="black", back_color="white")
img.save(os.path.join(app.config['QR_CODE_FOLDER'], filename))

# --- 路由 ---

@app.route('/')
def index():
"""主页 - 文件上传"""
return render_template('index.html')

@app.route('/upload', methods=['POST'])
def upload_file():
"""处理文件上传和二维码生成"""
if 'files' not in request.files:
return "No file part", 400
files = request.files.getlist('files')

if not files or all(f.filename == '' for f in files):
return "No selected file", 400

# 获取用户设置
try:
chunk_size_kb = int(request.form.get('chunk_size', 100)) # 默认100KB
display_speed = int(request.form.get('display_speed', 2)) # 默认2张/秒
except ValueError:
return "Invalid input for chunk size or display speed", 400

chunk_size_bytes = chunk_size_kb * 1024
delay_ms = int(1000 / display_speed) if display_speed > 0 else 500

# 为本次传输创建唯一会话ID和加密密钥
session_id = str(uuid.uuid4())
key = Fernet.generate_key()
cipher_suite = Fernet(key)

uploaded_files_info = []
all_chunks_data = [] # 存储所有文件的加密块数据

# 1. 处理每个上传的文件
for file in files:
if file:
filename = file.filename
filepath = os.path.join(app.config['UPLOAD_FOLDER'], filename)
file.save(filepath)

file_size = os.path.getsize(filepath)
file_hash = calculate_sha256(filepath)
file_type = file.content_type or 'unknown'

# 读取文件内容并Base64编码
with open(filepath, 'rb') as f:
file_content = f.read()
encoded_content = base64.b64encode(file_content).decode('utf-8')

# 准备元数据
metadata = {
'filename': filename,
'size': file_size,
'type': file_type,
'sha256': file_hash
}

# 将元数据和内容组合，然后加密
data_to_encrypt = json.dumps({
'metadata': metadata,
'content': encoded_content
}).encode('utf-8')

encrypted_data = cipher_suite.encrypt(data_to_encrypt)

# 分割加密后的数据
chunks = split_data(encrypted_data, chunk_size_bytes)
all_chunks_data.extend([(chunk, filename) for chunk in chunks]) # 保存块和文件名关联

uploaded_files_info.append({
'name': filename,
'size': file_size,
'hash': file_hash
})

# 2. 为所有块创建二维码
qr_filenames = []
total_chunks = len(all_chunks_data)
for i, (chunk_data, filename) in enumerate(all_chunks_data):
# 构造二维码数据：会话ID, 块索引, 总块数, 文件名标识, 加密块数据
# 为了简化，我们将密钥也编码进去（第一个二维码）
qr_data_dict = {
'session_id': session_id,
'index': i,
'total': total_chunks,
'filename': filename,
'data': base64.b64encode(chunk_data).decode('utf-8')
}

# 第一个二维码包含解密密钥
if i == 0:
qr_data_dict['key'] = key.decode('utf-8')

qr_data_str = json.dumps(qr_data_dict)
qr_filename = f"qr_{session_id}_{i}.png"
generate_qr_code(qr_data_str, qr_filename)
qr_filenames.append(qr_filename)


# 3. 存储会话信息 (虽然本次简化了密钥分发，但保留结构)
transfer_sessions[session_id] = {
'key': key.decode('utf-8'), # 存储为字符串
'total_chunks': total_chunks,
'chunks_received': {}, # {index: data}
'files_info': uploaded_files_info
}

# 4. 渲染展示页面
return render_template('index.html',
qr_files=qr_filenames,
delay_ms=delay_ms,
session_id=session_id,
files_info=uploaded_files_info)


# --- 接收端模拟 (简化版，实际需要前端JS扫描) ---

@app.route('/scanner')
def scanner():
"""扫描页面"""
return render_template('scanner.html')

# 模拟接收端扫描并重组文件的API端点
@app.route('/receive_chunk', methods=['POST'])
def receive_chunk():
"""接收扫描到的二维码数据块 (模拟)"""
data = request.json
qr_data_str = data.get('qr_data')

if not qr_data_str:
return jsonify({'status': 'error', 'message': 'No QR data received'}), 400

try:
qr_data = json.loads(qr_data_str)
except json.JSONDecodeError:
return jsonify({'status': 'error', 'message': 'Invalid QR data format'}), 400

session_id = qr_data.get('session_id')
index = qr_data.get('index')
total = qr_data.get('total')
filename = qr_data.get('filename')
encrypted_chunk_b64 = qr_data.get('data')
key_str = qr_data.get('key') # 可能来自第一个二维码

if not session_id or index is None or total is None or not encrypted_chunk_b64:
return jsonify({'status': 'error', 'message': 'Missing data in QR code'}), 400

# 检查或创建会话
if session_id not in transfer_sessions:
transfer_sessions[session_id] = {
'key': key_str, # 从第一个二维码获取
'total_chunks': total,
'chunks_received': {},
'files_info': {} # 简化处理
}
elif key_str:
transfer_sessions[session_id]['key'] = key_str # 更新密钥（如果第一个二维码后扫到）

session = transfer_sessions[session_id]

# 解密块
try:
cipher_suite = Fernet(session['key'].encode('utf-8'))
encrypted_chunk = base64.b64decode(encrypted_chunk_b64)
decrypted_chunk = cipher_suite.decrypt(encrypted_chunk)

# 解析解密后的内容
chunk_data = json.loads(decrypted_chunk.decode('utf-8'))
# 这里可以进一步处理 chunk_data['metadata'] 和 chunk_data['content']

# 存储解密后的内容（或原始加密块，取决于重组策略）
session['chunks_received'][index] = {
'data': chunk_data, # 存储解密后的完整数据
'filename': filename
}

except Exception as e:
return jsonify({'status': 'error', 'message': f'Decryption failed: {str(e)}'}), 500

# 检查是否所有块都已接收
if len(session['chunks_received']) == session['total_chunks']:
# 重组文件
try:
# 按索引排序
sorted_chunks = sorted(session['chunks_received'].items())

# 假设只有一个文件，或按filename分组处理
# 这里简化为处理第一个文件
if sorted_chunks:
# 重新组装内容 (需要按文件名分组)
files_content = {}
for idx, chunk_info in sorted_chunks:
fname = chunk_info['filename']
content = chunk_info['data']['content'] # Base64内容
if fname not in files_content:
files_content[fname] = []
files_content[fname].append(content)

for fname, parts in files_content.items():
# Base64解码所有部分并合并
full_base64_content = "".join(parts)
file_content = base64.b64decode(full_base64_content)

# 保存文件
output_path = os.path.join(app.config['RECEIVED_FOLDER'], f"received_{fname}")
with open(output_path, 'wb') as f:
f.write(file_content)

# 可以在这里验证SHA256 (chunk_info['data']['metadata']['sha256'])

# 清理会话
del transfer_sessions[session_id]
return jsonify({'status': 'success', 'message': 'File(s) received and saved.', 'download_url': url_for('download_file', filename=f"received_{list(files_content.keys())[0]}")})
else:
return jsonify({'status': 'error', 'message': 'No chunks to assemble'}), 500
except Exception as e:
return jsonify({'status': 'error', 'message': f'File assembly failed: {str(e)}'}), 500

return jsonify({'status': 'success', 'message': f'Chunk {index+1}/{total} received'})


@app.route('/download/<filename>')
def download_file(filename):
"""提供下载重组后的文件"""
try:
return send_file(os.path.join(app.config['RECEIVED_FOLDER'], filename), as_attachment=True)
except FileNotFoundError:
return "File not found", 404


if __name__ == '__main__':
app.run(debug=True)

<!DOCTYPE html>
<html>
<head>
<title>QR Code File Transfer - Sender</title>
<link rel="stylesheet" type="text/css" href="{{ url_for('static', filename='styles.css') }}">
</head>
<body>
<h1>QR Code File Transfer - Upload</h1>
<form method="post" action="/upload" enctype="multipart/form-data">
<label for="files">Choose files (max 25):</label>
<input type="file" id="files" name="files" multiple required><br><br>

<label for="chunk_size">QR Code Chunk Size (KB):</label>
<input type="number" id="chunk_size" name="chunk_size" value="100" min="1"><br><br>

<label for="display_speed">Display Speed (QR codes/second):</label>
<input type="number" id="display_speed" name="display_speed" value="2" min="1"><br><br>

<input type="submit" value="Upload and Generate QR Codes">
</form>

{% if qr_files %}
<hr>
<h2>File Information:</h2>
<ul>
{% for file in files_info %}
<li>{{ file.name }} ({{ "%.2f" | format(file.size / 1024.0) }} KB, SHA256: {{ file.hash }})</li>
{% endfor %}
</ul>
<h2>Generated QR Codes:</h2>
<!-- 幻灯片容器 -->
<div id="slideshow-container">
{% for qr_file in qr_files %}
<div class="mySlides">
<img src="{{ url_for('static', filename='qr_codes/' + qr_file) }}" style="width:100%">
</div>
{% endfor %}

<!-- Next and previous buttons -->
<a class="prev" onclick="plusSlides(-1)">&#10094;</a>
<a class="next" onclick="plusSlides(1)">&#10095;</a>
</div>
<br>
<!-- The dots/circles -->
<div style="text-align:center">
{% for qr_file in qr_files %}
<span class="dot" onclick="currentSlide({{ loop.index }})"></span>
{% endfor %}
</div>

<h3>Auto-Play Slideshow:</h3>
<button onclick="startSlideshow()">Start</button>
<button onclick="stopSlideshow()">Stop</button>
<p>Speed: {{ delay_ms }} ms per slide</p>

<script>
let slideIndex = 1;
showSlides(slideIndex);
let slideInterval = null;
const delay = {{ delay_ms }}; // milliseconds

function plusSlides(n) {
showSlides(slideIndex += n);
}

function currentSlide(n) {
showSlides(slideIndex = n);
}

function showSlides(n) {
let i;
let slides = document.getElementsByClassName("mySlides");
let dots = document.getElementsByClassName("dot");
if (n > slides.length) {slideIndex = 1}
if (n < 1) {slideIndex = slides.length}
for (i = 0; i < slides.length; i++) {
slides[i].style.display = "none";
}
for (i = 0; i < dots.length; i++) {
dots[i].className = dots[i].className.replace(" active", "");
}
slides[slideIndex-1].style.display = "block";
dots[slideIndex-1].className += " active";
}

function startSlideshow() {
if (slideInterval) stopSlideshow(); // Prevent multiple intervals
slideInterval = setInterval(() => {
plusSlides(1);
}, delay);
}

function stopSlideshow() {
clearInterval(slideInterval);
slideInterval = null;
}

// Optional: Start automatically
// window.onload = function() { startSlideshow(); }
</script>
{% endif %}
</body>
</html>

<!DOCTYPE html>
<html>
<head>
<title>QR Code File Transfer - Receiver</title>
<style>
#video {
width: 100%;
max-width: 600px;
height: auto;
border: 1px solid black;
}
#result {
margin-top: 20px;
padding: 10px;
border: 1px solid #ccc;
background-color: #f9f9f9;
}
</style>
</head>
<body>
<h1>QR Code File Transfer - Receiver</h1>
<p>Point your camera at the QR codes being displayed on the sender's screen.</p>

<!-- Scanner UI (需要集成 jsQR 或类似库) -->
<video id="video" width="300" height="200" autoplay muted></video>
<button id="startButton">Start Camera</button>
<button id="stopButton">Stop Camera</button>

<div id="result">
<p>Status: Waiting to start scanning...</p>
<p id="scanInfo">Scanned: 0 / 0</p>
<p id="speedInfo">Speed: 0 Kb/s</p>
<p id="message"></p>
</div>

<script src="https://cdn.jsdelivr.net/npm/jsqr@1.4.0/dist/jsQR.js"></script>
<script>
const video = document.getElementById('video');
const startButton = document.getElementById('startButton');
const stopButton = document.getElementById('stopButton');
const resultDiv = document.getElementById('result');
const scanInfo = document.getElementById('scanInfo');
const speedInfo = document.getElementById('speedInfo');
const messageP = document.getElementById('message');

let stream = null;
let scanning = false;
let lastScanTime = 0;
let lastScanCount = 0;

const constraints = {
video: {
facingMode: "environment", // Prefer back camera on mobile
width: { ideal: 1280 },
height: { ideal: 720 }
}
};

startButton.addEventListener('click', async () => {
try {
stream = await navigator.mediaDevices.getUserMedia(constraints);
video.srcObject = stream;
scanning = true;
lastScanTime = performance.now();
lastScanCount = 0;
scanContinuously();
} catch (err) {
console.error("Error accessing media devices:", err);
messageP.textContent = "Error accessing camera: " + err.message;
}
});

stopButton.addEventListener('click', () => {
scanning = false;
if (stream) {
const tracks = stream.getTracks();
tracks.forEach(track => track.stop());
video.srcObject = null;
}
messageP.textContent = "Camera stopped.";
});

function scanContinuously() {
if (!scanning) return;

// Use jsQR to scan the video element
const canvasElement = document.createElement('canvas');
const canvas = canvasElement.getContext('2d');
canvasElement.width = video.videoWidth;
canvasElement.height = video.videoHeight;

canvas.drawImage(video, 0, 0, canvasElement.width, canvasElement.height);
const imageData = canvas.getImageData(0, 0, canvasElement.width, canvasElement.height);
const code = jsQR(imageData.data, imageData.width, imageData.height, {
inversionAttempts: "dontInvert",
});

if (code) {
console.log("Scanned QR Code Data:", code.data);
// Send data to backend
fetch('/receive_chunk', {
method: 'POST',
headers: {
'Content-Type': 'application/json'
},
body: JSON.stringify({ qr_data: code.data })
})
.then(response => response.json())
.then(data => {
console.log('Success:', data);
messageP.textContent = data.message || "Chunk processed.";
if (data.status === 'success' && data.download_url) {
messageP.innerHTML += ` <a href="${data.download_url}" download>Download File</a>`;
}
// Update scan info (this is simplified, you'd need backend state)
lastScanCount++;
const now = performance.now();
const elapsedSeconds = (now - lastScanTime) / 1000;
if (elapsedSeconds > 1) { // Update speed every second
const speedKbps = (lastScanCount * 100 /* avg chunk size estimate kb */) / elapsedSeconds;
speedInfo.textContent = `Speed: ${speedKbps.toFixed(2)} Kb/s`;
lastScanTime = now;
lastScanCount = 0;
}
scanInfo.textContent = `Scanned: ${lastScanCount} (est.)`; // Placeholder
})
.catch((error) => {
console.error('Error:', error);
messageP.textContent = "Error sending  " + error;
});
}
// Continue scanning
requestAnimationFrame(scanContinuously);
}

// Initial check for API support
if (!navigator.mediaDevices || !navigator.mediaDevices.getUserMedia) {
messageP.textContent = "Your browser does not support camera access.";
startButton.disabled = true;
}
if (!window.jsQR) {
messageP.textContent = "QR code scanning library (jsQR) failed to load.";
startButton.disabled = true;
}


</script>
</body>
</html>

/* Slideshow container */
#slideshow-container {
max-width: 1000px;
position: relative;
margin: auto;
}

/* Hide the images by default */
.mySlides {
display: none;
}

/* Next & previous buttons */
.prev, .next {
cursor: pointer;
position: absolute;
top: 50%;
width: auto;
padding: 16px;
margin-top: -22px;
color: white;
font-weight: bold;
font-size: 18px;
transition: 0.6s ease;
border-radius: 0 3px 3px 0;
user-select: none;
}

/* Position the "next button" to the right */
.next {
right: 0;
border-radius: 3px 0 0 3px;
}

/* On hover, add a black background color with a little bit see-through */
.prev:hover, .next:hover {
background-color: rgba(0,0,0,0.8);
}

/* Caption text */
.text {
color: #f2f2f2;
font-size: 15px;
padding: 8px 12px;
position: absolute;
bottom: 8px;
width: 100%;
text-align: center;
}

/* Number text (1/3 etc) */
.numbertext {
color: #f2f2f2;
font-size: 12px;
padding: 8px 12px;
position: absolute;
top: 0;
}

/* The dots/bullets/indicators */
.dot {
cursor: pointer;
height: 15px;
width: 15px;
margin: 0 2px;
background-color: #bbb;
border-radius: 50%;
display: inline-block;
transition: background-color 0.6s ease;
}

.active, .dot:hover {
background-color: #717171;
}

/* Fading animation */
.fade {
animation-name: fade;
animation-duration: 1.5s;
}

@keyframes fade {
from {opacity: .4}
to {opacity: 1}
}
